DSK-1500VS Vertical Fog Machine.. Product #: Pure Lighting DSK-1500VS LED Vertical Fog Machine

DSK-1500VS Vertical

AC POWER

  • Input Voltage & Rate: 220-240 V, 50/60 Hz
  • Current Limiter Type: Breaker
  • Current Limiter Specifications: 8 A, 250 V
  • Total Power Consumption: 1,500 W
  • Operating Current: 6.5 A
  • Power Input Connector: Lockable PowerCon

HEATING

  • Heat Up Time: Appr. 4.0 min
  • Heater Type: Aluminum Heater Block

LIGHT SOURCE

  • LED Color: RGB
  • LED Type: Single Color
  • Power per LED: 3 W
  • Quantity of LED: 32 pcs
  • Quantity of RED: 11 pcs
  • Quantity of GREEN: 10 pcs
  • Quantity of BLUE: 11 pcs
  • Total Power of LED: 96 W
  • Quantity of Inner RED: 3 pcs
  • Quantity of Inner GREEN: 3 pcs
  • Quantity of Inner BLUE: 3 pcs
  • Quantity of Inner LED: 9 pcs
  • Total Power of Inner LED: 27 W
  • Quantity of Outer RED: 8 pc
  • Quantity of Outer GREEN: 7 pc
  • Quantity of Outer BLUE: 8 pcs
  • Quantity of Outer LED: 23 pcs
  • Total Power of Outer LED: 69 W

CAPACITY

  • Fluid Tank Capacity : 2.5 L / 0.7 Gal.

OUTPUT

  • Adjustable Volume: ×
  • Max Output Volume: Appr. 32,000 cfm
  • Max Output Height: Appr. 6.0~8.0 m
  • Fluid Consumption @ full volume : Appr. 160.0 mL/min
  • Maximum Continuous Duration @ full volume: Appr. 7 sec
  • Continuous Output : ×
  • Fuuly-loaded Cumulative Output Duration @ full volume: Appr. 15 min
  • Consumable Type for Standard Output Test: PRO-V

FEATURES

  • Physical Thermostat: √
  • Electronic Thermo-Control: √
  • Adjustable Output : ×
  • No-Fluid Protection: √
  • Instant-Stop: √
  • Supper-Jet: ×
  • Inner Flame Color Changing (IFCC): √

CONTROL

  • On-device Manual Control : 7-seg digital display & Physical manual trigger
  • Wireless Control: W-5 /RF 433MHz /Built-in
  • Wired Control: ×
  • Control Protocol: DMX-512
  • DMX Channel Range: 11
  • Data Connectors: 3- and 5-pin XLR

ACCESSORY

  • Power Cord: √
  • Wireless Controller Model: W-5 / RF 433MHz / Transmitter

CONSUMABLE

  • Consumable: PRO-V

WEIGHT & DIMENSIONS

  • Net Weight: 10 kg / 22 lb.
  • Gross Weight: 11 kg / 24.3 lb.
  • Machine Dimensions: 417 × 382 × 205 mm / 16.4 × 15 × 8.1 in.
  • Packing Dimensions: 495 × 455 × 260 mm / 19.5 × 17.9 × 10.2 in.
